POSTEK C168 series barcode label printer is an economical and practical barcode printer with the characteristics of saving cost, truly value for money and affordable price. This printer adopts 32-bit ultra-powerful CPU, 2MB ultra-large memory and 360m carbon tape loading, and can print Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8, UCC-128, Postnet, Plessey, HBIC, Telepen, FIM etc. one-dimensional bar codes and PDF417 etc. two-dimensional bar codes.
The POSTEK C168 is a thermal/direct‑thermal barcode label printer designed for high‑speed, high‑resolution printing. It features a 32‑bit CPU, 2 MB flash ROM, 2 MB SDRAM, and supports a wide range of barcode symbologies such as Code 39, Code 93, Code 128, Interleaved 2‑of‑5, EAN‑13, UPC‑A and more.
The printer offers RS‑232 and USB interfaces, operates from AC 100‑240 V (47‑63 Hz) with a 24 V 2.0 A output, and measures 236 × 291 × 199 mm, weighing about 2.5 kg. It can print labels up to 104 mm wide and 508 mm long at a maximum speed of 76.2 m/min, with a resolution of 203 dpi (8 dots/mm). This manual is written in Chinese.
| Printing method | Thermal / Direct‑thermal |
|---|---|
| Resolution | 203 dpi (8 dots/mm) |
| Maximum print speed | 76.2 m/min |
| Maximum label width | 104 mm |
| Maximum label length | 508 mm |
| Memory | 2 MB FLASH ROM, 2 MB SDRAM |
| Supported barcode types | Code 39, Code 93, Code 128, Interleaved 2‑of‑5, EAN‑13, UPC‑A, etc. |
| Interfaces | RS‑232 serial port, USB |
| Power supply | AC 100‑240 V, 47‑63 Hz input; 24 V 2.0 A output |
| Dimensions (W×D×H) | 236 × 291 × 199 mm |
| Weight | ≈2.5 kg |
It supports both thermal and direct‑thermal printing.
The printer provides a resolution of 203 dpi (8 dots per mm).
The device includes an RS‑232 serial port and a USB interface.
It operates from AC 100‑240 V, 47‑63 Hz and supplies 24 V 2.0 A to the printer.
