This document is the product manual of E2EV magnetic metal detector switch. It introduces the features and characteristics of the product, such as detection distance, output specifications, rated values/performance, and protection structure.
This manual covers the technical specifications, performance data, and dimensional information for the Omron E2EV proximity sensor series. It includes detailed installation instructions, wiring diagrams, and recommended mounting hardware.
Key sections describe rated values, detection distances, electrical characteristics, safety warnings, and environmental limits, helping users select the correct model and ensure reliable operation in industrial settings. This manual is written in Japanese.
| Operating voltage | DC12‑24 V |
|---|---|
| Maximum current consumption | 15 mA (typical) |
| Output type | NPN open‑collector, 100 mA |
The sensor is designed for a DC supply of 12 V to 24 V.
Typical current consumption is 15 mA or less.
No, the product must not be used for human body detection.
