The H8PS cam locator is a compact, high-performance locator with a variety of features, including 8-, 16-, and 32-point outputs, 0.5° high-precision settings, 1600r/min high-speed operation, a large LCD color display, a negative LCD display with backlight, a lead angle function, combination function, rotation speed display function, and pulse output function.
The document provides an overview of the H8PS cam locator, its purpose in PLC applications, and the basic connection methods. It includes details on power supply, signal types (NPN/PNP), and the LCD display used for status indication.
Operational instructions cover ON/OFF control, USB communication, and programming steps such as PRG, TST and RUN modes. Safety notes, wiring diagrams and troubleshooting tips are also included. This manual is written in Chinese.
| Maximum speed | 1600 r/min |
|---|---|
| Mounting standard | DIN96 96mm |
The cam locator can operate up to 1600 r/min.
