can build a flexible system of distributed control and centralized management
The document outlines safety precautions and regulatory compliance for the ID sensor units used with Omron PLC systems. It emphasizes the need for external safety measures, proper handling, and warns against disassembly or modification of the sensor modules.
Technical specifications such as rated voltages, current limits, operating temperature, environmental ratings, vibration and shock resistance, as well as physical dimensions of the modules are listed. The manual also includes functional details of communication programs and connection options. This manual is written in Japanese.
| Internal 5 V current | 260 mA |
|---|---|
| Internal 26 V current | 120 mA |
| External 24 V current | 360 mA |
| Operating temperature | 0 °C to +55 °C |
| Storage temperature | -20 °C to +75 °C |
| Vibration resistance | 10~57 Hz, 0.0753 mm amplitude |
| Shock resistance | 147 m/s² |
| Dimensions (CJ1W‑V600C11) | 35 × 100.5 × 130 mm |
No, the unit must not be disassembled.
External safety measures such as emergency stop circuits, interlock switches, and fault diagnosis must be implemented.
The unit operates from 0 °C up to +55 °C.
The module measures 35 mm × 100.5 mm × 130 mm (excluding protrusions).
