Rockwell Automation PowerFlex 40 Manuals

ManualLib has 4 documents for the Rockwell Automation PowerFlex 40: 3 quick start guides, 1 user manual. Every file can be read online or downloaded as a PDF for free.

Quick Start Guide 3User Manual 1

Key facts

Model
PowerFlex 40
Industry
Industrial
Documents
4
Languages
EN
Last added
2026-11-09

Start here

Rockwell Automation PowerFlex 40 FRN 1.xx - 4.xx Adjustable Frequency AC Drive Quick Start Guide

Rockwell Automation PowerFlex 40 FRN 1.xx - 4.xx Adjustable Frequency AC Drive Quick Start Guide

Quick Start Guide 22 pages · 735 KB · EN

This quick start guide summarizes the basic steps needed to install, start up and program the PowerFlex 40 Adjustable Frequency AC Drive, FRN 1.xx - 4.xx. It does not replace the PowerFlex 40 User Manual and is intended for qualified drive service personnel only.

The guide covers general precautions, mounting considerations, minimum clearances, ambient operating temperatures, disconnecting MOVs, CE conformity, drive ratings, input/output ratings, power terminal blocks and power wiring. It includes attention notes about high voltage capacitors, ESD-sensitive parts and correct application and installation.

Read online

Rockwell Automation PowerFlex 40 specifications

Output Frequency0-400 Hz (Programmable)
Efficiency97.5% (Typical)
Digital Control InputsInput Current = 6mA
4-20mA Analog Input Impedance250 ohm
Motor ProtectionI2t overload protection, 150% for 60 Secs and 200% for 3 Secs
Control Ride ThroughMinimum 0.5 Secs, typical 2 Secs

Source: Rockwell Automation PowerFlex 40 FRN 1.xx - 4.xx Adjustable Frequency AC Drive Quick Start Guide

All Rockwell Automation PowerFlex 40 documents by type

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What should be done before working on the drive?

Isolate the mains supply from the line inputs and wait three minutes for the capacitors to discharge to safe voltage levels.

From: Rockwell Automation PowerFlex 40 FRN 1.xx - 4.xx Adjustable Frequency AC Drive Quick Start Guide

What is the output frequency range?

The output frequency range is 0-400 Hz and is programmable.

From: Rockwell Automation PowerFlex 40 FRN 1.xx - 4.xx Adjustable Frequency AC Drive Quick Start Guide

Who should use this manual?

This manual is intended for qualified personnel who must be able to program and operate Adjustable Frequency AC Drive devices.

From: Rockwell Automation PowerFlex 40 Adjustable Frequency AC Drive User Manual

What is the purpose of this manual?

The manual provides basic information needed to install, start-up, and troubleshoot the PowerFlex 40 Adjustable Frequency AC Drive.

From: Rockwell Automation PowerFlex 40 Adjustable Frequency AC Drive User Manual

What personnel are qualified to use this guide?

This information is intended for qualified drive service personnel only.

From: Rockwell Automation PowerFlex 40 Adjustable Frequency AC Drive Quick Start Guide

How long must one wait after removing mains supply before working on the drive?

One must wait three minutes for capacitors to discharge to safe voltage levels.

From: Rockwell Automation PowerFlex 40 Adjustable Frequency AC Drive Quick Start Guide
