Key facts
- Brand
- Mitsubishi Electric
- Model
- FX5
- Category
- Automation control Equipment
- Industry
- Industrial
- Documents
- 12
- Languages
- EN · ZH · JA
- Last added
- 2026-11-06
Start here

Mitsubishi Electric MELSEC iQ-F FX5 Positioning Control Intelligent Function Module User's Manual
This manual provides detailed instructions for installing, wiring, and operating the MELSEC iQ-F FX5 Positioning Control Intelligent Function Module. It emphasizes safety precautions, including electrical hazards and mechanical risks, and outlines proper installation and maintenance procedures. The document also covers grounding, cable specifications, terminal wiring, and operational safety to prevent malfunctions or accidents.
Key safety warnings include disconnecting power before installation or maintenance, using appropriate cable ratings, and ensuring proper grounding. The manual also details precautions for startup, maintenance, and disposal, including interlock circuit design and environmental considerations.
Mitsubishi Electric FX5 specifications
| Number of analog input points | 4 points (4 channels) |
|---|---|
| Analog input voltage range | -10 to +10 V DC |
| Analog input current range | -20 to +20 mA DC |
| Internal electric supply (A/D conversion circuit) | 24 V DC 20 mA |
| Internal electric supply (Interface) | 5 V DC 10 mA |
| Dielectric withstand voltage | 500 V AC for one minute |
| Insulation resistance | 10 MΩ or higher |
| Conversion speed | Maximum 450 µs |
Source: Mitsubishi Electric FX5 User Manual (Analog Control)
All Mitsubishi Electric FX5 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- Mitsubishi Electric MELSEC iQ-F FX5 Positioning Control Intelligent Function Module User's Manual 570 p
- Mitsubishi Electric MELSEC iQ-R FX5 Micro PLC User Manual 56 p
- Mitsubishi Electric MELSEC iQ-F FX5 Analog User Manual 308 p
- Mitsubishi Electric FX5 User Manual (Analog Control) 180 p
- Mitsubishi Electric FX5 Application Manual 277 p
- Mitsubishi Electric FX5 Series PLC User Manual (OPC UA Edition) 108 p
- Mitsubishi Electric FX5 User Manual Ethernet Communication 298 p
- Mitsubishi Electric MELSEC iQ-F FX5 Ethernet Communication User Manual 216 p
- Mitsubishi Electric MELSEC iQ-F FX5 Series Programmable Controller User's Manual (CC-Link) 190 p
- Mitsubishi Electric MELSEC iQ-F FX5 Serial Communication User Manual 250 p
- Mitsubishi Electric MELSEC iQ-F FX5 Serial Communication User Manual 220 p
Instruction set, parameters and examples for configuring or programming the device.
Questions answered in these manuals
What safety circuits must be set up outside the PLC to ensure safe operation during power problems or PLC failure?
Set up an emergency stop circuit, a protection circuit, an interlock circuit for opposite movements, and an interlock circuit for upper and lower positioning limits.
From: Mitsubishi Electric MELSEC iQ-F FX5 Positioning Control Intelligent Function Module User's Manual
What is the minimum grounding resistance required for the CPU module's grounding terminal?
The grounding resistance must be 100 Ω or less.
From: Mitsubishi Electric MELSEC iQ-F FX5 Positioning Control Intelligent Function Module User's Manual
What safety circuits must be set externally?
External safety circuits such as emergency stop loops, protection loops, and interlock loops to prevent simultaneous opposite actions must be set up.
From: Mitsubishi Electric MELSEC iQ-R FX5 Micro PLC User Manual
What is the maximum recommended wire temperature rating?
Wires used must have a rated temperature exceeding 80°C, though this may vary depending on the extension equipment.
From: Mitsubishi Electric MELSEC iQ-R FX5 Micro PLC User Manual
What safety measures are required when the CPU module detects an error?
When the CPU module detects an error via its self-diagnostic function, all outputs turn OFF.
From: Mitsubishi Electric MELSEC iQ-F FX5 Analog User Manual
What is the minimum wire cross-section required for grounding the CPU and expansion modules?
You must use a wire with a cross-section of 2mm² or larger for the grounding connection.
From: Mitsubishi Electric MELSEC iQ-F FX5 Analog User Manual
