Key facts
- Brand
- Mitsubishi Electric
- Model
- MELSEC iQ-F FX5UC
- Category
- Industrial Robot
- Industry
- Industrial
- Documents
- 2
- Languages
- ZH
- Last added
- 2026-10-18
Start here
Mitsubishi Electric MELSEC iQ-R FX5UC Micro PLC User Manual
This document is the User Manual for the Mitsubishi Electric MELSEC iQ-R FX5UC micro programmable controller. It covers essential safety precautions, installation guidelines, wiring procedures, startup and maintenance instructions, and transport requirements to ensure safe and correct operation of the device. This manual is written in Chinese.
Read onlineMitsubishi Electric MELSEC iQ-F FX5UC specifications
| Operating Temperature | -20 to 55 C |
|---|---|
| Storage Temperature | -25 to 75 C |
| Operating Humidity | 5 to 95% RH, no condensation |
| Insulation Resistance | 10 MΩ or more |
Source: Mitsubishi Electric MELSEC iQ-F FX5U CPU Module Hardware Manual
All Mitsubishi Electric MELSEC iQ-F FX5UC documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many times can the SD memory card be installed or removed?
The manual states that installing and removing the SD memory card should not exceed 500 times.
From: Mitsubishi Electric MELSEC iQ-R FX5UC Micro PLC User Manual
What is the minimum wire size required for grounding the CPU module?
You must use a wire of 2mm² or larger to ground the CPU and expansion modules.
From: Mitsubishi Electric MELSEC iQ-R FX5UC Micro PLC User Manual
What safety precautions should be taken before using the device?
Read the MELSEC iQ-F FX5U User Manual (Hardware Edition) and related manuals to understand equipment knowledge, safety information, and precautions.
From: Mitsubishi Electric MELSEC iQ-F FX5U CPU Module Hardware Manual
What are the included accessories for the CPU module?
The package includes the CPU module, a dust cover, and manuals in Japanese/English and Chinese.
From: Mitsubishi Electric MELSEC iQ-F FX5U CPU Module Hardware Manual
