This document is the serial communication part of the user manual for Mitsubishi Electric's MELSEC iQ-F FX5 micro programmable controller. The document provides information on safety precautions, design considerations, wiring precautions, and precautions during startup and maintenance. The product features include safety circuit setting, interlock circuit, MC protocol support, intelligent function modules, etc.
This user manual provides detailed instructions on the serial communication features of the Mitsubishi Electric MELSEC iQ-F FX5 series micro programmable controllers. It covers essential safety precautions regarding installation, wiring, and maintenance to ensure safe operation.
The document details various communication functions such as Simple PLC Linking (EasyPLC), Parallel Linking, MC Protocol functionality, and inverter communication capabilities. It includes specific sections on system configuration, specifications, wiring diagrams, programming instructions for both master and slave stations, and troubleshooting guides. This manual is written in Chinese.
| Product Type | Micro Programmable Controller |
|---|---|
| Series Name | MELSEC iQ-F |
All external power must be disconnected before performing installation or wiring operations to prevent electric shock and product damage.
Control lines and communication cables must not be bundled with or placed near main circuits, high-voltage wires, load lines, or power lines.
