This manual provides safety precautions, installation instructions, wiring guidelines, startup procedures, and maintenance information for the Mitsubishi…
This document is the entry-level user manual for the Mitsubishi Electric MELSEC iQ-R FX5 series of micro programmable controllers. It outlines essential safety precautions regarding design, installation, wiring, startup, and maintenance to ensure safe operation and prevent accidents or equipment damage.
The guide covers critical warnings such as setting external safety circuits, handling inductive loads, and proper grounding procedures. It also details specific instructions for connecting power supplies, managing noise interference, and operating the battery backup system. This manual is written in Chinese.
External safety circuits such as emergency stop loops, protection loops, and interlock loops to prevent simultaneous opposite actions must be set up.
Wires used must have a rated temperature exceeding 80°C, though this may vary depending on the extension equipment.
The ground wire must be 2mm² or larger, and the grounding resistance should be 100Ω or less.
