Hayward PL-P-4-CUL Chlorinator User Manual
The document serves as a comprehensive guide for the Hayward Pro Logic PL-P-4-CUL automatic chlorinator system. It covers both manual and automated operation modes, detailing how to program settings such as filtration time, hyper-chlorination schedules, and salt concentration levels. The manual also explains how to interpret system indicators and manage water chemistry parameters like free chlorine, pH, alkalinity, and calcium hardness. This manual is written in French.
Read onlineAll Hayward PL-P-4-CUL documents by type
Mounting, wiring and first power-up. Read it before the hardware goes in.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the recommended range for free chlorine levels?
The recommended level for free chlorine is between 1.0 and 3.0 ppm.
What are the recommended salt levels for this system?
The ideal salt concentration should be maintained between 2700 and 3400 ppm.
What is the warranty period for Hayward Pro Logic automation products in residential pools?
Hayward/Goldline guarantees these products are free of defects in material and workmanship for a period of three (3) years.
From: Hayward PL-P-4-CUL Pro Logic Automation and Chlorination Installation Guide
What is the warranty period for Hayward Aqua Trol chlorination products?
Hayward/Goldline guarantees these products are free of defects in material and workmanship for a period of one (1) year.
From: Hayward PL-P-4-CUL Pro Logic Automation and Chlorination Installation Guide
What is the warranty period for Hayward Pro Logic automation products in residential private pools?
Hayward/Goldline guarantees these products are free from defects in material and workmanship for a period of three (3) years.
From: Hayward PL-P-4-CUL Pro Logic Automation and Chlorination Installation Guide
What is the minimum wire gauge required for the common local bonding grid connection?
The guide requires an isolated or bare copper conductor with a minimum size of 8 AWG US / 6 AWG Canada.
From: Hayward PL-P-4-CUL Pro Logic Automation and Chlorination Installation Guide
