A brief guide from Texas Instruments covering linear and logic devices, their applications, and key features across multiple product categories.
The Texas Instruments Linear and Logic 5‑Minute Guide provides a concise overview of TI’s analog product portfolio, highlighting new‑product priorities and key technologies for a range of markets such as computing, industrial automation, telecom, and consumer electronics. It introduces multiplexing switches, I2C expanders, RS‑232 interfaces, and ESD protection solutions.
The guide includes detailed sections on computing applications, I2C I/O expansion and LED drivers, RS‑232 serial interfaces with system‑level ESD protection, and advanced packaging options. Device tables list specifications such as PCI‑Express data rates, I2C bus frequencies, voltage ranges, and recommended part numbers. This manual is written in Chinese.
| PCI Express data rate | 2.5 Gbps |
|---|---|
| RS‑232 ESD protection (contact) | ±8 kV IEC 61000‑4‑2 |
| RS‑232 ESD protection (air‑gap) | ±15 kV IEC 61000‑4‑2 |
| Operating voltage range (ESD device) | +0.9 V to +5.5 V |
| TS2PCIE2212 package | 48‑Ball BGA (ZAH) |
It provides a concise overview of TI’s linear and logic devices, their applications, and key features for various markets.
They provide system‑level ESD protection of ±8 kV (contact) and ±15 kV (air‑gap) according to IEC 61000‑4‑2.
The TS2PCIE2212 is offered in a 48‑Ball BGA (ZAH) package.
