Texas Instruments Professional Computer Technical Reference Manual

About this manual

The Technical Reference Manual provides designers and engineers with a comprehensive description of the Texas Instruments Professional Computer. It includes an introduction to the system, detailed hardware component descriptions, power and interface specifications, and programming data such as coding tables, registers, and pin‑outs.

The document also contains system‑level information like the ROM BIOS, interrupt vectors, memory map, assembly drawings, parts lists, schematics, and a glossary of technical terms. Appendices cover controller boards, disk subsystem commands, and timing diagrams for various interfaces.

What's inside

• Introduction
• Hardware
• Systems
• Assembly Drawings and Lists of Materials
• Schematics
• Glossary
• Index

Specifications

Frequently asked questions

What is the part number of this manual?

The manual is identified as TI Part No. 2223216‑0001.

What is the maximum current rating for the controller board?

The maximum current rating is 2.5 A.
