Overview of SOURIAU feedthrough solutions including double‑ended receptacles, pressure seals and fireseals for aviation and military applications.
SOURIAU offers a full range of feedthroughs for aviation and military use, divided into three main categories: double‑ended receptacles, pressure seals and fireseals. The catalog presents typical applications such as aircraft junctions, fuel tanks and vehicle junctions, and provides a selection guide for the various series (8DB, 8PS, AM61, etc.).
Key features highlighted are extensive pressure capability, low leak rates, high‑temperature fire resistance and rugged construction. Specific series like 8STA are described for high‑vibration environments with soldered contacts on both sides of the bulkhead. The document also includes range‑extension options and technical data for each series.
| Pressure delta | up to 1 bar |
|---|---|
| Fire resistance temperature | up to 350A |
| Leak rate (8STA) | <1.10‑7 atm·cm³/s |
The 8STA series is designed for high‑vibration environments with soldered contacts on both sides of the bulkhead.
