A comprehensive product catalog detailing Samtec's high-speed, micro-rugged, and flex circuit interconnect solutions, including various connector types and…
This document serves as a catalog for Samtec's Signal Integrity Division, covering a wide range of high-speed and micro-rugged connectors. It details various connector types such as Tiger Eye, Tiger Beam, and Flex Stack, offering options for high density, low profile, and elevated designs with pitches ranging from .025" to .165". The catalog highlights capabilities in soldered and solderless systems, including hot bar or ZIF/LIF termination options.
| Pitch options | .025" (0,64mm), .050" (1,27mm) and 2mm (0.0787") |
|---|---|
| Frequency range | up to 10GHz |
| Mating cycles | Tested to 10,000 cycles |
| Contact material | Multi-finger BeCu contact |
Samtec offers in-house SI services for optimum design of conductor routing and terminations, as well as custom system analysis capability.
Yes, the catalog includes solderless systems and designs for hot bar or ZIF/LIF termination to the board.
The high-speed variety supports signal integrity up to 10GHz.
