Featured Samtec manuals
Samtec Precision RF Microwave/Millimeter Wave Interconnect Solutions Guide
This document provides an overview of Samtec's precision RF product line for microwave and millimeter‑wave applications. It describes full cable assemblies, board‑level interconnects, connectors and custom solutions that operate from 18 GHz up to 110 GHz.
The guide also outlines technical support services, test and measurement systems, and next‑generation waveguide technology, helping designers select the right interconnects for high‑density, high‑performance RF designs.
Covers: Product Overview · High‑Frequency RF Product Overview · Cable Assemblies · Board Connectors · Test & Measurement · Custom RF Solutions
Samtec HDAF Series Connector Product Leaflet
The HDAF series offers high‑density, high‑reliability connectors with selectable heights of 20 mm, 25 mm, 30 mm, and 35 mm, and pin counts of 299, 195 or 143. They support both single‑ended and differential signal configurations and are compatible with Molex HD Mezz series.
Key specifications include a rated current of 2.3 A at 80 °C, an operating temperature range of –55 °C to +125 °C, gold or tin plating, 19 mΩ contact resistance, a maximum working voltage of 200 VAC, 100 mating cycles, and RoHS compliance. Processing temperatures can reach up to 230 °C for 60 s or 260 °C for 20 s (three times). This manual is written in Chinese.
Covers: Insulation Material · Contact Material · Rated Current · Operating Temperature Range · Plating Options · Contact Resistance
Latest Samtec manuals
Samtec Precision RF Microwave/Millimeter Wave Interconnect Solutions Guide
Product Leaflet 24 pages · 7.7 MB · ENSamtec's guide details high‑frequency RF interconnect solutions covering 18 GHz‑110 GHz, including cables, connectors and custom options.
SAMTEC .025''SQ TERMINAL STRIPS TSM SERIES
samtec 025sq TERMINAL STRIPS TSM SERIES
SAMTEC IP68 USB CIRCULAR SCPU SCRUS SERIES
SCPU Series IP68 USB Circular Connectors are combinations of SCPU and SCRUS Series, SCPU series connectors are sealed circular USB receptacles, SCRUS series connectors are sealed circular USB receptacle cable assemblies, both are standard USB and mini USB sizes, with different electrical and mechanical specifications.
SAMTEC IP68 ETHERNET CIRCULAR SCPE SCRES SERIES
This document describes the features and characteristics of the SCRES and SCPE series sealed circular Ethernet plugs and receptacles, including waterproof rating, materials, operating temperature range, etc.
SAMTEC USB-B USBR-B USBC SERIES Manual
This document is a specification sheet for USB-B, USBR-B, and USBC series products.
Samtec HDAF Series Connector Product Leaflet
Product Leaflet 1 pages · 1.5 MB · ZHThe Samtec HDAF series connector product leaflet provides specifications, dimensions, and material details for high‑density, high‑reliability connectors.
Questions answered in Samtec manuals
What is the rated current of the HDAF series connector?
The connector is rated for 2.3 A at 80 °C.
What temperature range can the HDAF connector operate in?
It can operate from –55 °C up to +125 °C.
