Rockwell Automation 1769 CompactLogix Controller User Manual

About this manual

This manual introduces the 1769 CompactLogix controllers, covering their hardware overview, installation steps, wiring, and mounting requirements. It details how to configure serial and Ethernet/IP connections, set up ControlNet and DeviceNet networks, and manage I/O modules.

Safety guidelines are emphasized, referencing the SGI‑1.1 Safety Guidelines for solid‑state controls. The document also lists additional resources, firmware loading methods, CF‑card usage, battery maintenance, and troubleshooting information, with links to Rockwell Automation’s literature website for further technical documents. This manual is written in Chinese.

What's inside

• Introduction
• Controller Overview
• Installation
• Serial Connection
• Network Communication
• Controller Communication Management
• I/O Placement, Configuration and Monitoring
• Application Development
• PhaseManager Configuration
• CF Card Usage

Frequently asked questions

What safety guidelines apply to the CompactLogix controllers?

The Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (SGI‑1.1) apply to these controllers.

Where can I find additional resources for the CompactLogix controllers?

Additional resources are available at Rockwell Automation’s literature website: http://www.rockwellautomation.com/literature/

What models are covered by this user manual?

The manual covers the 1769-L31, 1769-L32C, 1769-L32E, 1769-L35CR, and 1769-L35E CompactLogix controllers.
