Rockwell Automation Logix5000 DeviceNet Modules User Manual

About this manual

This manual provides instructions for engineers and technicians who program or maintain industrial automation systems using Logix5000 controllers and DeviceNet modules. It assumes experience with programmable controllers, industrial control systems, and Windows operating systems.

The document is organized into chapters on preparation, offline and online network configuration, device connection, control logic, interlocks, communication with PanelView and RSView, performance tuning, troubleshooting, and specific guidance for FLEX™ and POINT™ I/O modules. This manual is written in Chinese.

What's inside

• Preparation
• Offline Network Configuration
• Connecting Devices to the Network
• Online Network Configuration
• Controlling Devices
• Interlocks and Shared Inputs
• Communicating with PanelView Terminals
• Communicating with RSView Projects
• DeviceNet Network Troubleshooting

Frequently asked questions

What safety guidelines apply to solid‑state controls used with these modules?

The manual references the "Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls" (publication SGI‑1.1).

Which Logix5000 controllers are compatible with the DeviceNet modules?

Compatible controllers include 1756 ControlLogix®, 1769 CompactLogix™, 1789 SoftLogix5800™, 1794 FlexLogix™, and PowerFlex®700S with DriveLogix™.
