The manual explains installation, configuration, and specifications of the Keyence SL‑T11R safety relay terminal and SL‑V series safety light curtain.
This document provides detailed information on the SL‑T11R safety relay terminal and the SL‑V series safety light curtain, including design features, quick‑connect wiring, and replaceable relay modules. It also describes the PC configuration software (SL‑VH1S) that enables functions such as programmable muting, beam‑axis intensity monitoring, and extended override times, helping to reduce on‑site installation time.
Installation guidance covers the space‑saving case design, quick connectors, dedicated power supply (SL‑U2), and mounting options that eliminate dead zones. Safety information, wiring diagrams, and environmental ratings are included to ensure compliance with IEC/EN/UL 61496‑1 Category 4 standards.
| Response time (ON to OFF) | 6 ms |
|---|---|
| Response time (OFF to ON) | 15 ms |
| Supply voltage (SL‑T11R) | 24 VDC ±10 % |
| Mechanical life | 10 million cycles or more |
| IP rating (control panel) | IP20, set inside panel with IP54 or more |
The SL‑T11R includes a quick connector, replaceable relay board, dedicated power supply (SL‑U2), and space‑saving case design that prevents wiring errors and simplifies integration with the SL‑V light curtain.
