This guide explains how to install and configure Infineon's DAvE Drive software for XC800, XC866, XC886CLM, XC888CLM and XC878CLM microcontrollers.
The document provides step‑by‑step instructions for downloading the DAvE Drive installer, running the setup wizard, and selecting the appropriate DIP files for the target microcontroller. It also covers creating a new project, configuring project settings such as the MCU model, and generating source code.
Further sections describe compiling the project, generating the HEX file, and using the MiniWiggler debug tool for programming and debugging. Supported motor types (BLDC and PMSM) and the range of Infineon microcontrollers compatible with DAvE Drive are also listed. This manual is written in Chinese.
