This manual provides specifications, installation steps, basic operation, settings, and network protocol information for the Delta DVPCOPM‑SL CANopen…
The application manual introduces the DVPCOPM‑SL CANopen communication module, its functions, and hardware components. It guides users through safe installation, address and function switch settings, and wiring of the CANopen connector. The document also covers building a CANopen network, using Delta CANopenBuilder software for configuration, ladder‑logic SDO/NMT/Emergency handling, LED indicator meanings, troubleshooting procedures, and detailed electrical and environmental specifications. This manual is written in Chinese.
| Supported CANopen baud rates | 10K, 20K, 50K, 125K, 250K, 500K, 800K, 1M bps |
|---|---|
| Power supply voltage | 24V DC (-15% ~ 20%) |
| Isolation voltage | 500 V |
The module supports CANopen baud rates of 10 Kbps up to 1 Mbps, including 10K, 20K, 50K, 125K, 250K, 500K, 800K, and 1M bps.
