Contrinex 360 ISC G 3806 BZ Signal Interface Product Datasheet

Technical datasheet for the Contrinex 360 ISC G 3806 BZ signal interface, covering electrical specs, dimensions and contact information.

Brand: Contrinex
Category: Industrial Supply
Document type: Datasheet
Language: English
Pages: 48
File format: PDF
File size: 5.3 MB
Published: 30 September, 2026
Updated: 30 September, 2026
MD5 checksum: 38FCC4A5287A8B0237AB9C1777206F7B
PDF: Contrinex 360 ISC G 3806 BZ Signal Interface Product Datasheet PDF

About this manual

The Contrinex 360 ISC G 3806 BZ is a signal interface product designed for industrial applications. This document provides the key electrical parameters, mechanical dimensions and model variants.

It also lists supply voltage ranges, current limits, frequency bandwidth, MTBF values and contact details for sales and support.

What's inside

Product Overview
Model Variants
Electrical Characteristics
Mechanical Dimensions
Connection Options
Contact Information

Specifications

Supply Voltage Range	5 V – 24 V
Operating Frequency Range	0 kHz – 100 kHz
Mean Time Between Failures (MTBF)	25 000 h (at +25 °C, 2000 rpm)
Typical Output Signal	Open‑collector, 5 V logic

Frequently asked questions

What supply voltage does the 360 ISC G 3806 BZ accept?

It can be powered from 5 V up to 24 V DC.

What frequency range can the interface handle?

It operates from 0 kHz up to 100 kHz.

What is the MTBF rating of the product?

The MTBF is specified as 25 000 hours at +25 °C and 2000 rpm.
