The AOpen MP965-DR mini PC supports Intel Core 2 Duo/Extreme CPUs, up to 4 GB DDR‑II memory, dual mini‑Card slots, and a range of I/O options.
The MP965-DR is a compact mini PC built on the Intel GM965+ICH8M chipset with an integrated Intel GFX500 MHz graphics engine. It is designed for Windows XP, MCE, and Vista operating systems and offers optional wireless, Bluetooth, and TV‑tuner modules.
Key features include support for Intel Core 2 Duo and Core 2 Extreme (Merom) processors, dual‑channel DDR‑II memory up to 4 GB, two mini‑Card expansion slots, a 5.1‑channel audio codec (ALC888), VGA and multi‑TV video outputs, Gigabit Ethernet, multiple USB 2.0 ports, and a 90 W universal power supply.
| CPU support | Intel Core 2 Duo, Core 2 Extreme (Merom) with Socket P |
|---|---|
| Chipset | Intel GM965+ICH8M |
| Graphics engine | Intel GFX500 MHz |
| Memory type | Dual‑channel DDR‑II 533/667 MHz SO‑DIMM |
| Maximum memory | 4 GB |
| Mini‑Card slots | 2 |
| Audio codec | 5.1‑channel (ALC888) |
| Video outputs | VGA (15‑pin D‑Sub) and multi‑TV out |
| LAN | Intel 10/100/1000 Ethernet |
| USB ports | 4 USB 2.0 ports (2 rear, 2 front) plus 2 on‑board |
| Dimensions (W×H×D) | 165 mm × 50 mm × 165 mm |
| Weight | 1.45 kg (2.4 lb) |
| Supported operating systems | Windows XP, MCE, Vista |
It supports Intel Core 2 Duo and Core 2 Extreme (Merom) processors using Socket P.
The system can accommodate up to 4 GB of DDR‑II memory in dual‑channel configuration.
It provides a VGA (15‑pin D‑Sub) connector and multi‑TV out for external displays.
Wireless, Bluetooth, and TV‑tuner modules are offered as optional accessories.
