The AOpen DE45-Pro is a compact PC with dual‑display support, Intel Core2 Duo CPU and extensive I/O options.
The DE45-Pro is a small‑form‑factor computer designed for digital signage, kiosks, gaming and other embedded applications. It features an Intel Core™2 Duo (Penryn) processor, up to 4 GB DDRII SO‑DIMM memory, integrated graphics and a variety of I/O ports including HDMI, dual VGA, USB, LAN and COM.
The system meets strict environmental specifications, operates from –10 °C to 55 °C, and includes optional wireless (802.11b/g) and storage options such as SATA, CF card and internal ExpressCard readers. Its compact dimensions (166 × 157 × 48 mm) and low weight (1.25 kg) make it suitable for tight installations.
| CPU | Intel Core™2 Duo (Penryn) 35 W TDP |
|---|---|
| Memory | DDRII SO‑DIMM 667/800 MHz, up to 4 GB |
| Graphics | Integrated GMA X4500MH |
| Storage Interfaces | 2.5" SATA HDD, CF Card, ExpressCard |
| Dimensions | 166 mm (H) × 157 mm (L) × 48 mm (W) |
| Weight | 1.25 kg |
| Operating Temperature | -10 °C to 55 °C |
It operates from –10 °C to 55 °C.
Yes, it supports dual displays.
It can use an 802.11b/g PCIe mini‑card with Atheros AR2423 chipset.
