AOpen AAXX44LLRR Motherboard User Manual

The AOpen AAXX44LLRR motherboard user manual provides installation steps, BIOS settings, hardware diagrams and troubleshooting guidance.

Brand: AOpen
Document type: User Manual
Language: Chinese
Pages: 112
File format: PDF
File size: 3.3 MB
Published: 28 September, 2026
Updated: 28 September, 2026
MD5 checksum: 1535E9490D3DD647CC00840C2677B0D0
PDF: AOpen AAXX44LLRR Motherboard User Manual PDF

About this manual

This manual covers everything needed to install and configure the AOpen AAXX44LLRR motherboard, including hardware installation, driver setup, BIOS configuration, and a glossary of terms. Detailed diagrams such as the motherboard layout and system block diagram help users understand the board's components.

Additional sections provide troubleshooting tips, technical support information, and instructions for registering the product. Contact details for AOpen worldwide support are also included. This manual is written in Chinese.

What's inside

Preface
Product Features
Quick Installation Guide
Motherboard Layout
System Block Diagram
Hardware Installation
BIOS Functions Overview
Troubleshooting
Technical Support

Specifications

Power Connector	ATX power connector
LAN Chip	10/100 Mbps LAN chip (AX4LR‑N only)
USB Ports	Three USB 2.0 connectors
Capacitor	3300 µF low‑impedance capacitor

Frequently asked questions

How do I clear the CMOS data?

Use the JP14 jumper to clear the CMOS data.

How can I enter the BIOS setup menu?

Press the designated key during POST to access the BIOS settings menu.

How do I update the BIOS on this motherboard?

Run the BIOS update utility provided for Windows operating systems.

Download PDF (3.3 MB)
