The AOPEN DE5100i is a compact, energy‑efficient mini‑ATX system offering dual‑display Full HD playback and robust connectivity for demanding AV applications.
The DE5100i high‑end computing system delivers unparalleled graphic performance for content‑heavy applications. Its mini‑ATX form factor provides flexible integration, 24/7 reliability, and green‑energy efficiency, making it ideal for digital signage and AV installations.
Key hardware includes an Intel Pentium B980 2.4 GHz CPU, up to 16 GB DDR3‑SO‑DIMM memory, integrated graphics, dual display support (HDMI/VGA/DVI/DisplayPort), multiple USB 2.0/3.0 ports, Gigabit Ethernet, and optional 3G/4G/Wi‑Fi modules. The unit measures 166 × 48 × 157 mm, weighs 1.03 kg, and operates from a 90 W (20 V, 4.5 A) AC adapter.
| Model name | DE5100i |
|---|---|
| Part Number | 91.DEA00.E1A0 |
| Dimensions (mm) | 166 x 48 x 157 mm |
| Weight | 1.03 kg |
| CPU | Intel Pentium B980 2.4 GHz |
| Maximum Memory | 16 GB |
| Graphics | Integrated in CPU |
| Display Ports | DVI‑I, VGA (via converter), DisplayPort, HDMI |
| Audio Codec | Realtek HD Audio Codec ALC662 |
| LAN | Intel Gigabit Ethernet WG82579LM |
| Power Adapter | 90 W (20 V, 4.5 A) |
| Operating Temperature | 0 ~ 50 °C |
| Idle Noise | 27 dB |
It uses an Intel Pentium B980 processor running at 2.4 GHz.
The AC adapter is rated at 90 W (20 V, 4.5 A).
It operates from 0 °C up to 50 °C.
