This manual provides detailed information on the SQX series electric valve actuators, including functional description, wiring diagrams, flow‑characteristic selection, and calibration procedures. It covers the standard and UL‑certified versions of the SQX32, SQX82 and SQX62 models.
The document also lists required accessories, ordering information, environmental limits, and safety precautions for installation and service work. Technical data such as supply voltage, travel, and signal types are presented for each model. This manual is written in Chinese.
| Travel | 20 mm |
|---|---|
| SQX32 Supply Voltage | AC 220V |
| SQX82 Supply Voltage | AC 24V |
| Operating Temperature (environment) | -15 °C to +50 °C |
| Valve Media Temperature | -25 °C to +140 °C |
All SQX actuators have a travel of 20 mm.
Yes, the SQX82U and SQX62U models are UL‑certified.
The actuators operate between –15 °C and +50 °C ambient temperature.
