SIMATIC TOP connect is a fast connection system that simplifies the connection work and avoids connection errors. It includes fully modular connections based on ready-made components and flexible connections using bundled wires. The connections are fast, reliable, and only require plug-in.
SIMATIC TOP connect is a rapid‑connection solution for Siemens SIMATIC S7‑300/400 systems. It offers two connection methods – a fully modular system using pre‑assembled terminal blocks and a flexible wiring system using bundled cables – both delivering quick, reliable, error‑free connections.
The system includes LED‑indicated terminal blocks, spring‑type and screw‑type terminals, and a range of pre‑assembled or custom cables that can carry up to 8 I/O channels or one byte of signals, with optional shielded cables for analog signals. Ordering data, part numbers and cable lengths are provided for easy procurement. This manual is written in Chinese.
| Signal capacity per cable | 8 channels or 1 byte |
|---|---|
| Terminal block options | spring‑type and screw‑type terminals with LED indication |
| Cable lengths available | 0.5 m to 5.0 m |
| Voltage input rating | 2 A |
It supports a fully modular connection using pre‑assembled terminal blocks and a flexible wiring connection using bundled cables.
A TOP connect cable can transmit up to 8 I/O channels or one byte of signals.
Yes, shielded cables are provided to ensure interference‑free transmission of sensitive analog signals.
Ordering data, part numbers and specifications are listed in the “订货数据” sections of the manual.
