This manual describes the installation and setup of the VISTA-128BP/VISTA-250BP distributed alarm control communication host. This manual includes an overview of the system, sub-system and host connection, installation of the control host, programming, data item description, timetable options, download programming tutorial, setting real-time clock, user password, system testing and so on.
This manual provides step‑by‑step instructions for installing the VISTA‑128BP and VISTA‑250BP control panels, including wiring of keypads, sensors, and auxiliary devices. It also covers programming of zones, schedules, and user passwords, as well as configuring the real‑time clock and testing the system.
The guide details hardware specifications, UL installation requirements, and optional modules such as VistaKey, VISTA Gateway, and wireless receivers. It includes troubleshooting tips, system command summaries, and appendices with detailed specifications and wiring diagrams. This manual is written in Chinese.
| Physical dimensions (standard enclosure) | 12 1/2" W x 14 1/2" H x 3" D |
|---|---|
| Alarm sound output | 10‑13.8 VDC, 1.7 A max |
| Auxiliary power output | 9.6‑13.8 VDC, 750 mA max |
| Backup battery | 12 VDC, 4 AH or 7 AH (YUASA NP4‑12 / NP7‑12) |
| Maximum addressable keypads | 31 |
| Maximum zones (VISTA‑128BP) | 128 |
The VISTA‑128BP control panel supports up to 128 zones.
Up to 31 addressable keypads can be connected to the system.
Recommended batteries are YUASA NP4‑12 (12 V, 4 AH) or YUASA NP7‑12 (12 V, 7 AH).
