The document describes the features and characteristics of the piston rod cylinders KPZ series from Bosch Rexroth AG, including compact cylinders, single-acting cylinders that do not compress back, magnetic pistons, and elastic cushioning.
This guide covers the technical data, dimensions, pressure ratings, and installation instructions for the Bosch Rexroth KPZ series piston rod cylinders. It includes tables of bore sizes, stroke lengths, and thread specifications, as well as safety and legal notices.
Contact information for Bosch Rexroth sales and support is provided at the end of the document, along with a disclaimer that the data are for reference only and subject to change.
| Bore size range | 16–100 mm |
|---|---|
| Pressure range | 1.5–10 bar |
| Stroke lengths | 16, 20, 25, 32, 40 mm |
| Thread size | #0:M5‑G1/8 |
The KPZ cylinders are rated for pressures from 1.5 bar up to 10 bar.
Bore sizes range from 16 mm to 100 mm.
