About this manual

This guide explains how to install, commission and operate the Bosch Rexroth LU1/LU2 lock fixed unit. It includes safety notes, mounting instructions, and technical specifications.

Additional sections cover required mounting accessories, pressure and temperature limits, and contact information for support. This manual is written in German.

What's inside

  • Installation
  • Operation
  • Technical Data
  • Mounting Accessories
  • Safety Information
  • Contact Information

Specifications

Operating pressure2 bar to 8 bar
Temperature range-20 °C to 480 °C
Maximum flow5 ym

Frequently asked questions

Which mounting accessories are required for the LU1/LU2 unit?

The mounting accessories LU3, LU4 and LU5 must be ordered separately as accessories.

What is the operating pressure range of the lock unit?

The unit operates between 2 bar and 8 bar.
