This document describes the features and characteristics of Bosch Rexroth AG's pressure control valve to electrical proportional valve series ED02, including interfaces, electronic connections, signal connections, installation components, etc. This product features E/P pressure control valve, analog control, CE certification, etc.
This manual covers the ED02 series pressure regulator valve, describing its technical data, installation steps, and usage instructions. It includes details on pneumatic and electrical connections, safety notes, and recommended oil types.
Key features include a 24 V DC supply, IP65 protection, and a wide ambient temperature range. Performance curves, wiring diagrams, and accessory part numbers are provided for proper integration into pneumatic systems. This manual is written in Chinese.
| Working voltage | DC 24 V |
|---|---|
| Power consumption | max. 0.3 A |
| Ambient temperature range | -25 °C to +80 °C |
| Electrical connection type | Signal interface, M12 5‑pin connector |
The pressure dew point must be at least 15 °C lower than the ambient and media temperature.
Only oil approved by Bosch Rexroth may be used.
The valve draws a maximum of 0.3 A.
The valve uses a signal interface with an M12 5‑pin connector.
