Introduces the front panel and rear panel composition, functional characteristics, supported standards and installation examples of Lenovo Tiangong iSpirit 2924G/F switch.
The iSpirit 2924G/F is a managed Gigabit Ethernet switch designed for enterprise work‑group and IP metro‑area network access. It offers 24 RJ‑45 10/100Base‑T ports, four expansion slots for fiber, copper or stacking modules, and supports up to 4094 VLANs, SNMP, IGMP, and various security features.
The manual details front‑ and rear‑panel descriptions, installation procedures for desktop, rack or cabinet mounting, power requirements, boot‑ROM startup options, and console‑based firmware upgrades. Safety warnings and environmental guidelines are also included to ensure proper and safe deployment. This manual is written in Chinese.
| Ethernet ports | 24 RJ‑45 10/100Base‑T auto‑negotiation ports |
|---|---|
| Expansion ports | 4 slots (Gigabit fiber, 10/100/1000Base‑T, stacking) |
| Maximum power consumption | 50 W |
| Supported VLANs | Up to 4094 VLANs |
| Maximum copper cable length | 140 m (CAT5) for 10/100/1000Base‑T |
| SFP multimode fiber reach | 275 m (62.5 µm, 850 nm) |
It provides 24 RJ‑45 10/100Base‑T auto‑negotiation ports.
The switch’s maximum power consumption is 50 W.
The copper ports support up to 140 m of CAT5 cable.
