ThinkCentre M70e Series is a vertical computer launched by Lenovo, which adopts Intel 64-bit dual-core architecture processor, Intel latest chipset, DDR3 memory, supports SATA 2.0(300MB/s) architecture, Gigabit Ethernet network, front audio and USB 2.0 sockets, with a 15-month product life cycle, supports all ThinkVantage Technologies, and offers a three-year warranty.
This manual describes the Lenovo ThinkCentre M70e series upright desktop, its hardware components, supported operating systems, and available security and warranty features. It is intended for end‑users and service technicians who need to set up, operate, and maintain the system.
Key specifications include an Intel Pentium dual‑core E5500 processor, up to 4 GB DDR3 RAM, a 320 GB SATA 2.0 hard drive, Gigabit Ethernet, multiple USB 2.0 ports, and a 280 W switchable power supply. The system ships with Windows 7 Professional and Lenovo’s ThinkVantage utilities, and is covered by a three‑year parts and on‑site service warranty. This manual is written in Chinese.
| Processor | Intel Pentium dual‑core E5500 (2.8 GHz, 2 MB L2 cache, 800 MHz FSB) |
|---|---|
| Memory | Up to 4 GB DDR3‑1066 (PC3‑8500) 2 × 240‑pin DIMM |
| Storage | 320 GB 7200 rpm SATA 2.0 hard drive |
| Chipset | Intel G41 |
| Graphics | Intel GMA X4500 |
| Network | Gigabit Ethernet |
| Power Supply | 280 W, 110 V/240 V switchable |
| Warranty | Three years parts, three years on‑site service |
The system supports Windows 7 Professional.
The warranty provides three years of parts and three years of on‑site service.
It includes Gigabit Ethernet networking.
