This document is the user manual for Lenovo Network (Shenzhen) Co., Ltd.'s iSpirit series adaptive Ethernet switches. The manual provides information on the product's inventory, usage, terms of use, and also includes detailed descriptions of the product's appearance, performance characteristics, unpacking installation, and initialization process. Additionally, the manual provides detailed technical information and warranty policies.
This manual covers the iSpirit1200E Ethernet switch, describing its hardware layout, safety precautions, and basic operation. It includes step‑by‑step installation instructions and configuration guidance for network administrators.
The document also details the LED indicator functions, supported network standards, power requirements, and provides a full list of technical specifications for the device. This manual is written in Chinese.
| Network Speed | 10/100 Mbps |
|---|---|
| Supported Standards | IEEE802.3 10BASE‑T, IEEE802.3u 100BASE‑TX |
| MDI/MDIX Uplink | Supported |
| Power Supply | 100‑250 VAC, 50‑60 Hz |
| LED Indicators | Power, Link/Activity, Speed |
The iSpirit1200E supports 10 Mbps and 100 Mbps Ethernet speeds.
It complies with IEEE802.3 10BASE‑T and IEEE802.3u 100BASE‑TX standards.
Yes, the switch includes MDI/MDIX uplink functionality.
The device operates on 100‑250 VAC at 50‑60 Hz.
