MITAC Desktop Board PD10RI is a low-power, compact and lightweight Mini-ITX board that supports Intel Braswell N3160/J3160 processors with Intel HD Graphics 505 integrated graphics, and supports 2 204-pin DDR3L SO-DIMM memory slots with a maximum capacity of 8GB.
The MITAC PD10RI is a low-profile Mini-ITX desktop board designed for embedded applications. It features an Intel Braswell N3160/J3160 processor with integrated graphics and supports up to 8 GB of DDR3L system memory. The board includes various peripheral interfaces such as USB, SATA, LAN, and multiple serial ports.
| Form Factor | Low-profile Mini-ITX (20mm x 170.18mm x 170.18mm) |
|---|---|
| Processor | Intel Braswell N3160/J3160 |
| Memory Support | Dual channel DDR3L 1066/1333 SO-DIMMs, up to 8 GB |
| LAN Controller | Realtek RTL8111G-CG Gigabit Ethernet |
| Operating Temperature | 0 °C to +60 °C |
The board supports up to 8 GB of system memory on a single SO-DIMM or 4 GB each by using two SO-DIMMs.
Yes, the board is designed to be passively cooled in a properly ventilated chassis.
Users can select UEFI USB Hard Disk Drive, UEFI USB KEY Drive, or Windows Boot Manager as the boot device.
