The Mitac Thin Mini-ITX Board PD10EHI is a low-power microcomputer motherboard that uses an Intel Elkhart Lake processor, supports DDR4 3200 memory, supports up to 32GB of memory, and is equipped with a Realtek ALC888 audio codec.
The document provides a feature summary for the MiTAC PD10EHI Thin Mini-ITX Board, highlighting its low-profile form factor (20mm height), Intel Elkhart Lake processor chipset, and dual-channel DDR4 SO-DIMM memory support up to 32GB. It outlines expansion capabilities including PCI Express 3.0 x1, multiple M.2 slots for SATA/USB/NVMe, and Mini PCIe connectivity.
The guide further details external and internal I/O interfaces, such as USB 3.1 Gen2, HDMI, DisplayPort, RS232 headers, and SATA ports. It includes specific product specifications for display features (HDMI 1.4, eDP 1.3), connector pinouts for LVDS and eDP panels, front panel header definitions, and BIOS/UEFI boot option configurations.
| Form Factor | Low-profile Mini-ITX (20mm x 170.18mm x 170.18mm) |
|---|---|
| Processor Chipset | Intel Elkhart Lake Processor with integrated graphics |
| Main Memory Support | Dual channel DDR4 3200 SO-DIMMs, Max 32GB |
| Audio Controller | Realtek ALC888 audio codec |
| PCI Express Connector | PCI Express 3.0 x1 connector |
| Operating Temperature | 0°C to +60°C |
The board supports a maximum of 32GB using dual channel DDR4 3200 SO-DIMMs.
It supports M.2 slots for USB2.0, SATAIII, and PCIex1, but it does not support M.2 M Key NVMe SSD.
The board supports Windows 10 64-bit and Linux (support by request).
