This is a development board for embedded systems, which includes 1 UART, 1 USB 2.0 OTG port, 1 header for programming, 1 Line- out/Mic-in, 1 USB2.0 port header, 1 Power Switch, 12V internal 4- pin DC-in connector, 1 Raspberry Pi 40-pin header.
This document serves as a quick installation guide for the MiTAC ND108T industrial embedded computer. It details the placement of the mainboard (MB) and describes the various connectors available on the device, including power inputs, USB headers for programming and data, UART ports for debugging, and a 40-pin header compatible with Raspberry Pi.
Connect via RS232 to the J22 UART header and press any key within 3 seconds of power-on.
The device is rated for an industrial temperature grade ranging from -40C to 85C.
The system defaults to an HDMI display with a resolution of 1280x720.
You must set the connection to 115200baud to access the UART port.
