The MITAC Desktop Board PD10TI Product Guide describes the main features of the board, including form factor, processor, memory, chipset, integrated graphics, external graphics, audio, traditional I/O, and expansion capabilities.
This document serves as a product guide for the MITAC PD10TI Desktop Board, outlining its key features such as the passively-cooled dual-core Intel Atom processor, DDR3 memory support, and various I/O capabilities including Gigabit Ethernet and USB ports. It provides a summary of specifications and a diagram of board components.
| Form Factor | Mini-ITX (170 millimeters [6.7 inches] x 170 millimeters [6.7 inches]) |
|---|---|
| Processor | Passively-cooled, soldered-down dual-core Intel Atom processor |
| Main Memory | Two 204-pin DDR3 SO-DIMM sockets |
| Max Memory | Up to 4 GB |
| Chipset | Intel NM10 Express Chipset |
| Integrated Graphics | Intel Graphics Media Accelerator 3650 |
| LAN | Intel 82574L Gigabit Ethernet |
| USB Ports | Seven USB 2.0 ports |
| SATA Connectors | Two Serial ATA (SATA) 3.0 Gb/s connectors |
Press the
Enable the F7 prompt in BIOS Setup, then press F7 during boot to enter the BIOSFlash Update tool and select the .BIO file from a USB drive.
It indicates that memory size has decreased since the last boot, or if no memory was removed, that memory may be bad.
