MITAC Desktop Board PH10LU is a micro computer motherboard, which uses the fourth generation Intel Core processor, supports DDR3 1066/1333/1600 MHz memory, supports up to 32GB of system memory, and is equipped with Intel® Graphics Media Accelerator 4600 integrated graphics, supports PCIe 3.0 x16 external graphics.
The MITAC PH10LU is a Micro-ATX desktop board designed for 4th generation Intel® Core processors with a maximum TDP of 95 W. It features an Intel® Q87 chipset, support for up to 32 GB of DDR3 memory, and integrated Intel® Graphics Media Accelerator 4600 graphics. The board includes multiple expansion slots, USB 3.0 support, and various legacy I/O options.
| Form Factor | Micro-ATX (244 millimeters x 244 millimeters) |
|---|---|
| Processor Support | 4th generation Intel Core processor family |
| Max Processor TDP | 95 W |
| Chipset | Intel Q87 Platform Controller Hub |
| Integrated Graphics | Intel Graphics Media Accelerator 4600 |
| Max System Memory | 32 GB |
| Memory Type | DDR3 1066/1333/1600 MHz SO-DIMMs |
| Operating Temperature | 0 °C to +50 °C |
| LAN Support | Intel I217 Gigabit LAN |
The board supports processors with a maximum wattage of 95 W Thermal Design Power (TDP).
The board supports DDR3 1066/1333/1600 MHz SO-DIMMs, with DDR3 1333 MHz and 1600 MHz SO-DIMMs operating at 1066 MHz only.
Yes, it includes a Legacy I/O Controller (Nuvoton NCT6104D) providing Serial Port, Parallel port via header, and Hardware management support.
