Maxtor DiamondMax16 60/80/120/160GB Product Manual

This product manual introduces the features and usage of Maxtor DiamondMax16 60/80/120/160GB hard drives.

Brand: Maxtor
Category: Hard disk
Document type: User Manual
Language: English
Pages: 50
File format: PDF
File size: 942 KB
Published: 16 October, 2023
Updated: 16 October, 2023
MD5 checksum: 1C654D3ECB852A331B6AC317BCDE8BC4
PDF: Maxtor DiamondMax16 60/80/120/160GB Product Manual PDF

About this manual

This manual provides technical information for OEM engineers and systems integrators regarding the installation and use of Maxtor DiamondMax16 hard disk drives. It covers product descriptions, specifications, handling precautions, and ATA bus interface details.

What's inside

Introduction
Product Description
Product Specifications
Handling and Installation
ATA Bus Interface and ATA Commands
Service and Support
Breaking the 137 Gigabyte Storage Barrier

Specifications

Spin Speed	5400 RPM
Access Time	12.6 ms
Buffer Size	2 MB
Interface	Ultra ATA/133
Addressing	48-bit
Shock Resistance	300 Gs
Start/Stop Cycles	50K

Frequently asked questions

Who should use this manual?

This manual provides technical information for OEM engineers and systems integrators regarding the installation and use of Maxtor hard drives.

Where can I get repair information?

Drive repair should be performed only at an authorized repair center. Contact the Maxtor Product Support Center at 1-800-2MAXTOR.

What are the key features of the DiamondMax16?

Key features include ANSI ATA-5/6 compliance, UltraDMA Mode 5 support, 48-bit addressing, and a 2 MB buffer.
