JUMO B 70.6510.0 Paperless Recorder Operating Manual

About this manual

This document serves as the operating manual for the JUMO B 70.6510.0 Paperless Recorder. It provides detailed instructions on commissioning, operation, visualization of measurement data, and parameter setting via the device interface or optional PC setup program.

The guide covers technical aspects such as analog inputs, digital signals, counters, and math/logic modules. It also details installation requirements, electrical connections, and the use of associated software tools like PCA3000 for evaluation.

What's inside

• Introduction
• Device description
• Operation and visualization
• Configuration parameters
• Setup program
• PC programs
• Installation
• Electrical connection

Frequently asked questions

What safety regulations must be followed when returning modules or components?

When returning modules, assemblies, or components, you must observe the regulations of EN 61340-5-1 and EN 61340-5-2 regarding protection from electrostatic phenomena.

What fuse values are required for the external fusing based on the supply voltage?

For a supply of 20 to 53V AC/DC, a 5A slow-blow fuse is required, and for 110 to 240V AC, a 5A slow-blow fuse is also required.

What is the maximum nominal voltage for the installation regulations cited in the manual?

The installation and electrical connection must conform to regulations for power circuits with nominal voltages below 1000V.
