The JUMO LOGOSCREEN paperless recorder series provides TFT screens, up to 350,000 values storage, optional Ethernet, and web‑server functions for industrial…
JUMO LOGOSCREEN paperless recorders replace conventional paper recorders with a TFT color graphics screen and electronic data storage, offering fast retrieval, secure archiving and convenient PC evaluation. The series includes the 500 cf, nt and fd models, each with configurable analog inputs, internal memory up to 350 000 values and optional external storage.
The devices integrate lifecycle data management, web‑server visualization, batch reporting and optional math/logic functions. Supporting software such as PCA3000, PCC and SVS3000 enables configuration, archiving, and visualization of process data, while the fd version meets FDA 21 CFR Part 11 requirements for electronic records.
| Display | 5‑inch (cf) / 5.5‑inch (nt/fd) TFT color graphics screen |
|---|---|
| Measuring inputs | 3 or 6 analog inputs (cf); 3/6/9/12/15/18 analog inputs (nt/fd) |
| Internal memory | Up to 350 000 measured values |
| External storage | CF memory card, USB memory stick (optional) |
| Power supply | AC/DC 20‑53 V, 48‑63 Hz (cf); AC 100‑240 V, 48‑63 Hz (nt/fd) |
| Protection rating | IP54 (standard) / IP65 (optional) |
| Interfaces | RS232/485 (optional), Ethernet (optional), USB device/host |
| Special features | Lifecycle data management, web‑server function, batch reporting, math/logic functions |
The LOGOSCREEN 500 cf provides 3 or 6 analog inputs for RTD temperature probes, thermocouples, current or voltage signals.
Yes, the LOGOSCREEN fd version fulfills FDA 21 CFR Part 11 requirements for electronic records and signatures.
The PCA3000 PC evaluation software is used for administration, archiving, visualization and evaluation of historical process data.
Yes, optional Ethernet and RS232/485 interfaces allow network connection and remote data access via a built‑in web server.
