Key facts
- Manuals
- 6
- Languages
- EN · ZH
- Last added
- 2026-10-03
Featured JUMO manuals
JUMO Form B Push-in Resistance Thermometer Data Sheet
The JUMO push‑in resistance thermometers with terminal head Form B are designed for temperature measurement in liquids and gases, suitable for HVAC, heating installations, ovens, furnaces and plant engineering. The terminal head operates up to +100 °C ambient temperature and is available in aluminium (Form B, BUZ, BUZH) or plastic (BBK) versions.
Technical data include replaceable Pt100 (or Pt500/Pt1000) measuring inserts, optional analog or programmable transmitters (4‑20 mA, 0‑10 V), and stainless‑steel protection tubes. Various order codes define length, process connection type and extra options such as different terminal head forms.
Covers: Technical data · Dimensions · Order details · Order codes · Stock versions
JUMO 902931 Wtrans Receiver Data Sheet
The JUMO Wtrans Receiver 902931 is a universal receiver for JUMO wireless measurement sensors. It supports a Modbus‑enabled RS485 interface, can connect up to 16 probes, and provides up to four analog outputs (0‑20 mA or 0‑10 V) or two relay outputs. The device operates on AC 110‑240 V or AC/DC 20‑30 V and works in the ISM bands 868.4 MHz (EU/China) or 915 MHz (US, AU, CA, NZ).
The receiver includes a two‑line LCD, four configuration buttons, and LED status indicators. It can be mounted on a DIN‑rail (35 mm × 7.5 mm) and offers isolated communication ports, including RS485, TTL/RS232, and USB/TTL converters. Environmental ratings cover –20 °C to +50 °C operation, IP20 protection, and vibration resistance up to 1 g. This manual is written in Chinese.
Covers: Technical Data · Operation and Configuration · Electrical Data · Interface Settings · Installation · Selection Guide
JUMO dTRON 304/308/316 B70.3041.0 User Manual
This manual describes the JUMO dTRON control system series, covering the 304, 308, 316 and B70.3041.0 models. It includes product features, safety information, wiring diagrams, and step‑by‑step installation instructions.
Technical specifications such as supply voltage, current consumption, communication interfaces (RS422/485, PROFIBUS‑DP), input/output counts and module dimensions are listed, along with guidance for configuration and troubleshooting.
Covers: Product Overview · Technical Specifications · Installation Guide · Operation Instructions · Communication Interfaces · Safety and Compliance
JUMO Form B Push-in Thermocouples Data Sheet
The JUMO push‑in thermocouples with terminal head Form B are designed for temperature measurement in liquids and gases. They are suitable for heating installations, ovens, furnaces and plant engineering, with ambient temperature rating up to +100 °C.
The data sheet lists terminal head variants (Form B, BUZ, BUZH, BBK), protection‑tube materials (steel and ceramic), measuring‑insert types, process‑connection options, and order‑code configurations. It also provides dimensions, nominal lengths and transmitter output options (4‑20 mA/20‑4 mA).
Covers: Technical data · Terminal head Form B · Protection tube materials · Measuring insert types · Process connection · Order details
Latest JUMO manuals
JUMO Form B Push-in Resistance Thermometer Data Sheet
Datasheet 4 pages · 133 KB · ENData sheet for JUMO push‑in resistance thermometers with terminal head Form B, covering specs, dimensions and order options.
JUMO 902931 Wtrans Receiver Data Sheet
Datasheet 10 pages · 403 KB · ZHTechnical data sheet for the JUMO Wtrans receiver model 902931, a wireless measurement unit with Modbus RS485 interface.
JUMO dTRON 304/308/316 B70.3041.0 User Manual
User Manual 68 pages · 1.5 MB · ENThe JUMO dTRON manual provides installation, operation, and technical specifications for models 304, 308, 316 and B70.3041.0.
JUMO Form B Push-in Thermocouples Data Sheet
Datasheet 3 pages · 80 KB · ENTechnical data and specifications for JUMO push‑in thermocouples with terminal head Form B, covering temperature ranges, protection tubes, and order codes.
JUMO LOGOSCREEN Paperless Recorder Product Overview
Product Leaflet 16 pages · 5.5 MB · ENThe JUMO LOGOSCREEN paperless recorder series provides TFT screens, up to 350,000 values storage, optional Ethernet, and web‑server functions for industrial…
JUMO Wtrans RF T01 Wireless Sensor Receive Unit User Manual
User Manual 80 pages · ZHOperating instructions and specifications for the JUMO Wtrans RF T01 wireless sensor receive unit.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in JUMO manuals
What temperature range can the Form B terminal head measure?
The Form B terminal head is rated for temperatures from –50 °C up to +600 °C.
Which transmitter types are available for these thermometers?
Both analog transmitters (4‑20 mA or 0‑10 V) and programmable transmitters (4‑20 mA/20‑4 mA) can be integrated into the terminal head.
How many probes can be connected to the receiver?
The receiver can connect up to 16 wireless measurement probes.
What analog output options are available?
Model 902931/10 provides four analog outputs that can be configured for 0‑20 mA or 0‑10 V signals.
What is the required supply voltage and current for the modules?
The modules require a supply voltage of 23 V and draw about 30 mA.
How many binary inputs does a dTRON module provide?
Each module provides two binary inputs.
