FrSky R9M 2019 Module Instruction Manual

This document is the instruction manual for FrSky R9M 2019(EU) module. It mainly introduces the features and usage methods of the module.

Brand: FrSky
Category: Other
Document type: User Manual
Language: English
Pages: 2
File format: PDF
File size: 2.5 MB
Published: 15 October, 2023
Updated: 15 October, 2023
Model: R9M 2019
MD5 checksum: 87EEDE1CC2F9E00787E0AE7A0E9EB70E
PDF: FrSky R9M 2019 Module Instruction Manual PDF

About this manual

The FrSky R9M 2019 is a long-range, low-latency RC system module operating at 868MHz. It supports both telemetry (25mW) and no-telemetry modes (200mW/500mW) and features a Smart Port for high-speed digital data transmission. The module is compatible with FrSky R9 ACCESS series transmitters and various receivers.

What's inside

Introduction
Features
Specifications
Binding Procedure
Failsafe Mode
Range Check
Smart Port
LED Indication

Specifications

RF Operating Frequency	868MHz
Voltage Range	DC 6.5V~13V
Telemetry Interface	Smart Port
Modulations	PXX or CPPM
Numbers of Channel	8CH / 16CH

Frequently asked questions

What is the operating frequency of the R9M 2019 EU module?

The module operates at 868MHz.

How do I switch between Telemetry and No Telemetry modes?

You can switch modes using the switches on the module, which changes the LED blinking pattern to indicate the selected power level.

What should I do if I lose signal during flight?

The receiver has three failsafe modes: No Pulse, Hold, and Custom, which can be set on the transmitter.
