This manual covers safety instructions, installation precautions, wiring details, and specifications for the Toshiba 1400XL Plus Series UPS. It includes sections on general safety symbols, required circuit‑breaker ratings, ambient temperature limits, and battery handling procedures.
Later chapters describe operating modes, troubleshooting, preventive maintenance, and external layout dimensions with optional receptacle panels. Detailed model‑specific information for 2.4 kVA, 3.6 kVA, 6 kVA, and 8 kVA units is provided, along with battery replacement guidelines and wiring diagrams.
| Circuit breaker rating (2.4 kVA) | 15 A |
|---|---|
| Circuit breaker rating (3.6 kVA) | 20 A |
| Circuit breaker rating (6 kVA) | 30 A |
| Nominal battery voltage (2.4 kVA) | 96 V |
| Nominal battery voltage (6 kVA) | 216 V |
| Nominal battery voltage (8 kVA) | 252 V |
| Standard line cord length | 6 ft |
A 20 A circuit breaker is required for the 3.6 kVA model.
