HS-2700RH is radiation hardened internally compensated operational amplifiers which employ dielectric isolation to achieve excellent DC and dynamic performance with very low quiescent power consumption
The HS-2700RH is a radiation hardened internally compensated operational amplifier that employs dielectric isolation to achieve excellent DC and dynamic performance with very low quiescent power consumption. It is designed for high gain signal amplification, instrumentation, and active filtering applications requiring fast, accurate response over a wide range of signal frequencies.
| Quiescent Supply Current (Max) | 150 µA |
|---|---|
| Common Mode Rejection Ratio (Typ) | 106 dB |
| Input Offset Voltage | 0.5 mV |
| Input Bias Current | 5.0 nA |
| Open-Loop Gain | 300,000 V/V |
| Gain Bandwidth | 1 MHz |
| Slew Rate | 20 V/µs |
| Operating Supply Voltage Range | +5.5V to +20V |
The HS-2700RH is suited for high gain amplifiers, instrumentation amplifiers, active filters, telemetry systems, and battery-powered equipment.
Yes, the HS-2700RH is a radiation hardened internally compensated operational amplifier.
The maximum quiescent supply current is 150 µA.
