The SA614A is an improved monolithic low-power FM IF system incorporating two limiting intermediate frequency amplifiers, quadrature detector, muting, logarithmic received signal strength indicator, and voltage regulator. The SA614A features higher IF bandwidth (25MHz) and temperature compensated RSSI and limiters permitting higher performance application compared with the SA604. The SA614A is available in a 16-lead dual-in-line plastic and 16-lead SO (surface-mounted miniature) package.
The Philips SA614A is an improved monolithic low-power FM IF system that incorporates two limiting intermediate frequency amplifiers, a quadrature detector, muting, a logarithmic received signal strength indicator (RSSI), and a voltage regulator. It is designed for applications requiring higher IF bandwidth (25MHz) and temperature-compensated RSSI compared to the SA604.
| Low power consumption | 3.3mA typical |
|---|---|
| Temperature range | -40 to +85 °C |
| Single supply voltage | 4.5 to 8.0 V |
| DC current drain | 2.5 to 4.0 mA |
| IF bandwidth | 25MHz |
| Excellent sensitivity | 1.5uV for 12dB SINAD |
| AM rejection | 25 to 33 dB |
| Signal-to-noise ratio | 68 dB |
The SA614A is suitable for cellular radio FM IF, high performance communications receivers, intermediate frequency amplification and detection up to 25MHz, RF level meters, spectrum analyzers, instrumentation, and FSK and ASK data receivers.
The typical power consumption is 3.3mA.
The operating ambient temperature range is -40 to +85 °C.
