The 74F299 is an 8-bit universal shift/storage register with 3-State outputs. Four modes of operation are possible: Hold (store), shift left, shift right and parallel load. The parallel load inputs and flip-flop outputs are multiplexed to reduce the total number of package pins. Additional outputs are provided for flip-flops Q0 and Q7 to allow easy serial cascading. A separate active-LOW Master Reset is used to reset the register.
The Philips 74F299 is an 8-bit universal shift/storage register featuring 3-State outputs designed for bus-oriented applications. It supports four distinct modes of operation: Hold (store), shift left, shift right, and parallel load. The device contains eight edge-triggered D-type flip-flops with interstage logic to perform these synchronous operations efficiently.
| Operating Temperature Range | 0 to +70 °C |
|---|---|
| Bit Width | 8-bit |
The device supports Hold (store), shift left, shift right, and parallel load operations.
The maximum clock frequency is 115 MHz.
The recommended supply voltage is 4.5 V to 5.5 V.
The operating free-air temperature range is 0 °C to +70 °C.
