BZX585 series is a low-power voltage regulator diodes encapsulated in an ultra small SOD523 plastic SMD package. The diodes are available in the normalized E24 ± 2 % (BZX585-B) and ± 5 % (BZX585-C) tolerance range. The series consists of 37 types with nominal working voltages from 2.4 V to 75 V.
The document describes the Philips BZX585 series, which consists of 37 types of low-power voltage regulator diodes. These devices are encapsulated in an ultra-small SOD-523 plastic surface-mounted device (SMD) package and feature a working voltage range from nominal 2.4 V to 75 V.
| Total power dissipation (max) | 300 mW |
|---|---|
| Non-repetitive peak reverse power dissipation (max) | 40 W |
| Working voltage range | 2.4 V to 75 V |
| Package type | SOD-523 |
The series is available in normalized E24 + 2% (BZX585-B) and + 5% (BZX585-C) tolerance ranges.
The device can be stored between -65 °C and +150 °C.
