The S.BUS System Channel Changer is a tool for setting the channel to S.BUS servo and S.BUS decoder of Futaba S.BUS system.
The Futaba SBC-1 is a tool designed for the Futaba S.BUS system to set the channel number on S.BUS servos and decoders. It connects to a single S.BUS servo and a battery to facilitate the channel selection process via a CHANNEL SELECT switch and a set switch.
| Dimensions | 1.54x1.02x0.39in. (39x26x10mm) |
|---|---|
| Weight | 0.28oz. (7.8g) |
| Power Requirement | Ni-Cd, Ni-MH 4 cells to 5 cells equivalent battery |
| Operating Temperature Range | -10 to +45° |
The LED lights steadily when the CHANNEL SELECT switch number and the channel set at the S.BUS servo are the same.
The LED blinks slowly when the CHANNEL SELECT switch number and the channel set at the S.BUS servo are different.
